270L Belt Drive Air Compressor 7.5hp 3ph

Model No. SAC32775B
List Price
Promotion Price
Buy Online
Image Thumbnail Image Thumbnail Image Thumbnail Image Thumbnail Image Thumbnail Image Thumbnail
List Price
Promotion Price

  • Air Displacement: 29.7cfm(840L/min).
  • Maximum Free Air Delivery: 26.2cfm(742L/min).
  • Maximum Pressure: 145psi(10bar).
  • Heavy-duty 3-phase compressor suitable for the professional workshop.
  • Triple cylinder pump system coupled with a 7.5hp motor maximizes performance to keep running costs low compared to single stage, single phase models.
  • Pump features heavy-duty full cast cylinders, capped by alloy heads for improved heat dissipation and long-life.
  • Heavy-duty drive guards protect belt and flywheel that is designed to force air over the pump to aid cooling.
  • Supplied with full CE certification, test certificates and operating/maintenance manual.
  • Includes a drain valve for easy release of condensed water build-up in the tank.
  • 3 Year guarantee*.
  • This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.

Air Displacement cfm(L/min):

29.7(840)

Maximum Free Air Delivery cfm(L/min):

26.2(742)

Maximum Pressure:

145psi(10bar)

Minimum Rated Supply:

32A

Motor Output:

7.5hp

Nett Weight:

193kg

Oil Capacity:

1.7L

Outlet:

1/2"BSP

Phase:

3ph

Receiver Capacity:

270L

Size (W x D x H):

1500 x 620 x 1080mm

Speed:

970rpm

Supply:

415V/32A

Model No.

Description

List Price (Exc. VAT)

List Price (Inc. VAT)

Bearing 6304 B/6304 Spare Part Image

B/6304

Bearing 6304

Name: Bearing 6304

Model No: B/6304

£14.29

£17.15

Bearing 6308 B/6308 Spare Part Image

B/6308

Bearing 6308

Name: Bearing 6308

Model No: B/6308

£45.99

£55.19

Tank 270ltr (so) SAC32775B.01 Spare Part Image

SAC32775B.01

Tank 270ltr (so)

Name: Tank 270ltr (so)

Model No: SAC32775B.01

£879.99

£1055.99

Air Compressor Pump 3 Cylinder SAC32775B.02 Spare Part Image

SAC32775B.02

Air Compressor Pump 3 Cylinder

Name: Air Compressor Pump 3 Cylinder

Model No: SAC32775B.02

£629.95

£755.94

Electrical motor (External 7.5hp 400-660v) SAC32775B.03 Spare Part Image

SAC32775B.03

Electrical motor (External 7.5hp 400-660v)

Name: Electrical motor (External 7.5hp 400-660v)

Model No: SAC32775B.03

£459.95

£551.94

Motor Fan Cover SAC32775B.03A Spare Part Image

SAC32775B.03A

Motor Fan Cover

Name: Motor Fan Cover

Model No: SAC32775B.03A

£23.49

£28.19

Motor Fan SAC32775B.03B Spare Part Image

SAC32775B.03B

Motor Fan

Name: Motor Fan

Model No: SAC32775B.03B

£18.29

£21.95

Motor pulley 140mm SAC32775B.04 Spare Part Image

SAC32775B.04

Motor pulley 140mm

Name: Motor pulley 140mm

Model No: SAC32775B.04

£58.76

£70.51

Belt guard SAC32775B.05 Spare Part Image

SAC32775B.05

Belt guard

Name: Belt guard

Model No: SAC32775B.05

£112.76

£135.31

Plastic clip (belt guard) SAC32775B.06 Spare Part Image

SAC32775B.06

Plastic clip (belt guard)

Name: Plastic clip (belt guard)

Model No: SAC32775B.06

£0.99

£1.19

Bracket (belt guard) SAC32775B.07 Spare Part Image

SAC32775B.07

Bracket (belt guard)

Name: Bracket (belt guard)

Model No: SAC32775B.07

£11.96

£14.35

Copper tube 18mm SAC32775B.10 Spare Part Image

SAC32775B.10

Copper tube 18mm

Name: Copper tube 18mm

Model No: SAC32775B.10

£33.11

£39.73

Rubber foot 60x20mm m10 SAC32775B.13 Spare Part Image

SAC32775B.13

Rubber foot 60x20mm m10

Name: Rubber foot 60x20mm m10

Model No: SAC32775B.13

£21.14

£25.37

Base plate SAC32775B.14 Spare Part Image

SAC32775B.14

Base plate

Name: Base plate

Model No: SAC32775B.14

£120.29

£144.35

Safety Valve Ø3/8" 11bar SAC32775B.15 Spare Part Image

SAC32775B.15

Safety Valve Ø3/8" 11bar

Name: Safety Valve Ø3/8" 11bar

Model No: SAC32775B.15

£60.56

£72.67

Pressure switch 10/16amp 4-12bar SAC32775B.16 Spare Part Image

SAC32775B.16

Pressure switch 10/16amp 4-12bar

Name: Pressure switch 10/16amp 4-12bar

Model No: SAC32775B.16

£117.99

£141.59

Decompression tube SAC32775B.17 Spare Part Image

SAC32775B.17

Decompression tube

Name: Decompression tube

Model No: SAC32775B.17

£7.99

£9.59

Check valve SAC32775B.18 Spare Part Image

SAC32775B.18

Check valve

Name: Check valve

Model No: SAC32775B.18

£30.86

£37.03

Electrical cable SAC32775B.19 Spare Part Image

SAC32775B.19

Electrical cable

Name: Electrical cable

Model No: SAC32775B.19

£12.86

£15.43

Ball valve 1/2"bsp female x 2 SAC32775B.20 Spare Part Image

SAC32775B.20

Ball valve 1/2"bsp female x 2

Name: Ball valve 1/2"bsp female x 2

Model No: SAC32775B.20

£16.46

£19.75

Pressure gauge 230psi back fitting d;63mm SAC32775B.21 Spare Part Image

SAC32775B.21

Pressure gauge 230psi back fitting d;63mm

Name: Pressure gauge 230psi back fitting d;63mm

Model No: SAC32775B.21

£18.71

£22.45

Cross connector SAC32775B.22 Spare Part Image

SAC32775B.22

Cross connector

Name: Cross connector

Model No: SAC32775B.22

£19.29

£23.15

Spring washer 10mm SAC32775B.P02 Spare Part Image

SAC32775B.P02

Spring washer 10mm

Name: Spring washer 10mm

Model No: SAC32775B.P02

£0.79

£0.95

Washer of pulley SAC32775B.P03 Spare Part Image

SAC32775B.P03

Washer of pulley

Name: Washer of pulley

Model No: SAC32775B.P03

£0.99

£1.19

Flywheel SAC32775B.P04 Spare Part Image

SAC32775B.P04

Flywheel

Name: Flywheel

Model No: SAC32775B.P04

£125.81

£150.97

Bolt m8x25 SAC32775B.P05 Spare Part Image

SAC32775B.P05

Bolt m8x25

Name: Bolt m8x25

Model No: SAC32775B.P05

£0.79

£0.95

Bearing cover SAC32775B.P06 Spare Part Image

SAC32775B.P06

Bearing cover

Name: Bearing cover

Model No: SAC32775B.P06

£26.29

£31.55

Cover gasket SAC32775B.P07 Spare Part Image

SAC32775B.P07

Cover gasket

Name: Cover gasket

Model No: SAC32775B.P07

£4.29

£5.15

Oil seal SAC32775B.P08 Spare Part Image

SAC32775B.P08

Oil seal

Name: Oil seal

Model No: SAC32775B.P08

£3.99

£4.79

Woodruff Key 8x30mm SAC32775B.P10 Spare Part Image

SAC32775B.P10

Woodruff Key 8x30mm

Name: Woodruff Key 8x30mm

Model No: SAC32775B.P10

£2.29

£2.75

Crank shaft SAC32775B.P11 Spare Part Image

SAC32775B.P11

Crank shaft

Name: Crank shaft

Model No: SAC32775B.P11

£81.99

£98.39

Oil drain plug SAC32775B.P14 Spare Part Image

SAC32775B.P14

Oil drain plug

Name: Oil drain plug

Model No: SAC32775B.P14

£2.29

£2.75

Oil leveler 3/4" SAC32775B.P15 Spare Part Image

SAC32775B.P15

Oil leveler 3/4"

Name: Oil leveler 3/4"

Model No: SAC32775B.P15

£7.29

£8.75

Cylinder 90mm SAC32775B.P16 Spare Part Image

SAC32775B.P16

Cylinder 90mm

Name: Cylinder 90mm

Model No: SAC32775B.P16

£47.79

£57.35

Exhaust elbow 1" SAC32775B.P17 Spare Part Image

SAC32775B.P17

Exhaust elbow 1"

Name: Exhaust elbow 1"

Model No: SAC32775B.P17

£9.79

£11.75

Air filter assembly (element & housing) SAC32775B.P18 Spare Part Image

SAC32775B.P18

Air filter assembly (element & housing)

Name: Air filter assembly (element & housing)

Model No: SAC32775B.P18

£19.79

£23.75

Complete cooler (low pressure) SAC32775B.P19 Spare Part Image

SAC32775B.P19

Complete cooler (low pressure)

Name: Complete cooler (low pressure)

Model No: SAC32775B.P19

£19.99

£23.99

Oil filler plug SAC32775B.P20 Spare Part Image

SAC32775B.P20

Oil filler plug

Name: Oil filler plug

Model No: SAC32775B.P20

£2.49

£2.99

Cylinder gasket SAC32775B.P21 Spare Part Image

SAC32775B.P21

Cylinder gasket

Name: Cylinder gasket

Model No: SAC32775B.P21

£15.74

£18.89

Low pressure connecting rod SAC32775B.P22 Spare Part Image

SAC32775B.P22

Low pressure connecting rod

Name: Low pressure connecting rod

Model No: SAC32775B.P22

£14.49

£17.39

Piston 90mm SAC32775B.P24 Spare Part Image

SAC32775B.P24

Piston 90mm

Name: Piston 90mm

Model No: SAC32775B.P24

£18.49

£22.19

Piston pin 20x80mm SAC32775B.P25 Spare Part Image

SAC32775B.P25

Piston pin 20x80mm

Name: Piston pin 20x80mm

Model No: SAC32775B.P25

£6.79

£8.15

Piston ring set ( 90x30mm) SAC32775B.P26 Spare Part Image

SAC32775B.P26

Piston ring set ( 90x30mm)

Name: Piston ring set ( 90x30mm)

Model No: SAC32775B.P26

£12.79

£15.35

Valve seat gasket 90mm SAC32775B.P27 Spare Part Image

SAC32775B.P27

Valve seat gasket 90mm

Name: Valve seat gasket 90mm

Model No: SAC32775B.P27

£16.64

£19.97

Column pin 3x10 SAC32775B.P28 Spare Part Image

SAC32775B.P28

Column pin 3x10

Name: Column pin 3x10

Model No: SAC32775B.P28

£1.29

£1.55

Valve spring SAC32775B.P29 Spare Part Image

SAC32775B.P29

Valve spring

Name: Valve spring

Model No: SAC32775B.P29

£0.79

£0.95

Suction valve seat SAC32775B.P30 Spare Part Image

SAC32775B.P30

Suction valve seat

Name: Suction valve seat

Model No: SAC32775B.P30

£4.99

£5.99

Exhaust valve seat SAC32775B.P32 Spare Part Image

SAC32775B.P32

Exhaust valve seat

Name: Exhaust valve seat

Model No: SAC32775B.P32

£5.29

£6.35

Head gasket 90mm SAC32775B.P36 Spare Part Image

SAC32775B.P36

Head gasket 90mm

Name: Head gasket 90mm

Model No: SAC32775B.P36

£26.49

£31.79

Joint 1" (T-Shape) SAC32775B.P37 Spare Part Image

SAC32775B.P37

Joint 1" (T-Shape)

Name: Joint 1" (T-Shape)

Model No: SAC32775B.P37

£15.79

£18.95

Aluminium cylinder head 90mm SAC32775B.P38 Spare Part Image

SAC32775B.P38

Aluminium cylinder head 90mm

Name: Aluminium cylinder head 90mm

Model No: SAC32775B.P38

£22.49

£26.99

Spring washer 10mm SAC32775B.P39 Spare Part Image

SAC32775B.P39

Spring washer 10mm

Name: Spring washer 10mm

Model No: SAC32775B.P39

£0.79

£0.95

Bolt m10x50 SAC32775B.P40 Spare Part Image

SAC32775B.P40

Bolt m10x50

Name: Bolt m10x50

Model No: SAC32775B.P40

£0.79

£0.95

Exhaust elbow 1/2" SAC32775B.P41 Spare Part Image

SAC32775B.P41

Exhaust elbow 1/2"

Name: Exhaust elbow 1/2"

Model No: SAC32775B.P41

£6.49

£7.79

Bolt m6x40 SAC32775B.P42 Spare Part Image

SAC32775B.P42

Bolt m6x40

Name: Bolt m6x40

Model No: SAC32775B.P42

£0.79

£0.95

Spring washer 6mm SAC32775B.P43 Spare Part Image

SAC32775B.P43

Spring washer 6mm

Name: Spring washer 6mm

Model No: SAC32775B.P43

£0.79

£0.95

Hp aluminium cylinder head 65mm SAC32775B.P44 Spare Part Image

SAC32775B.P44

Hp aluminium cylinder head 65mm

Name: Hp aluminium cylinder head 65mm

Model No: SAC32775B.P44

£17.54

£21.05

Pipe nut g 3/4" SAC32775B.P45 Spare Part Image

SAC32775B.P45

Pipe nut g 3/4"

Name: Pipe nut g 3/4"

Model No: SAC32775B.P45

£2.49

£2.99

Hp head gasket 65mm SAC32775B.P46 Spare Part Image

SAC32775B.P46

Hp head gasket 65mm

Name: Hp head gasket 65mm

Model No: SAC32775B.P46

£6.29

£7.55

Hp valve seat plate 65mm SAC32775B.P47 Spare Part Image

SAC32775B.P47

Hp valve seat plate 65mm

Name: Hp valve seat plate 65mm

Model No: SAC32775B.P47

£8.99

£10.79

Hp valve seat 65mm SAC32775B.P48 Spare Part Image

SAC32775B.P48

Hp valve seat 65mm

Name: Hp valve seat 65mm

Model No: SAC32775B.P48

£1.61

£1.93

Aluminium Gasket SAC32775B.P49 Spare Part Image

SAC32775B.P49

Aluminium Gasket

Name: Aluminium Gasket

Model No: SAC32775B.P49

£6.29

£7.55

Hp valve seat gasket 65mm SAC32775B.P50 Spare Part Image

SAC32775B.P50

Hp valve seat gasket 65mm

Name: Hp valve seat gasket 65mm

Model No: SAC32775B.P50

£6.29

£7.55

High pressure cylinder 65mm SAC32775B.P51 Spare Part Image

SAC32775B.P51

High pressure cylinder 65mm

Name: High pressure cylinder 65mm

Model No: SAC32775B.P51

£38.06

£45.67

Hp piston ring set (62x3mm) SAC32775B.P52 Spare Part Image

SAC32775B.P52

Hp piston ring set (62x3mm)

Name: Hp piston ring set (62x3mm)

Model No: SAC32775B.P52

£8.36

£10.03

Internal Circlip 15.4mm OD SAC32775B.P53 Spare Part Image

SAC32775B.P53

Internal Circlip 15.4mm OD

Name: Internal Circlip 15.4mm OD

Model No: SAC32775B.P53

£0.99

£1.19

Hp piston (65mm) SAC32775B.P54 Spare Part Image

SAC32775B.P54

Hp piston (65mm)

Name: Hp piston (65mm)

Model No: SAC32775B.P54

£9.99

£11.99

Hp piston pin 14.5x57mm SAC32775B.P55 Spare Part Image

SAC32775B.P55

Hp piston pin 14.5x57mm

Name: Hp piston pin 14.5x57mm

Model No: SAC32775B.P55

£3.79

£4.55

High pressure connectimg rod SAC32775B.P56 Spare Part Image

SAC32775B.P56

High pressure connectimg rod

Name: High pressure connectimg rod

Model No: SAC32775B.P56

£24.29

£29.15

Breather m16x1.5 SAC32775B.P57 Spare Part Image

SAC32775B.P57

Breather m16x1.5

Name: Breather m16x1.5

Model No: SAC32775B.P57

£5.49

£6.59

Complete cooler (hp) SAC32775B.P58 Spare Part Image

SAC32775B.P58

Complete cooler (hp)

Name: Complete cooler (hp)

Model No: SAC32775B.P58

£89.79

£107.75

Bolt m10x30 SAC32775B.P59 Spare Part Image

SAC32775B.P59

Bolt m10x30

Name: Bolt m10x30

Model No: SAC32775B.P59

£0.79

£0.95

Rear cover gasket SAC32775B.P60 Spare Part Image

SAC32775B.P60

Rear cover gasket

Name: Rear cover gasket

Model No: SAC32775B.P60

£2.29

£2.75

Rear cover SAC32775B.P61 Spare Part Image

SAC32775B.P61

Rear cover

Name: Rear cover

Model No: SAC32775B.P61

£6.49

£7.79

Bolt m6x20 SAC32775B.P62 Spare Part Image

SAC32775B.P62

Bolt m6x20

Name: Bolt m6x20

Model No: SAC32775B.P62

£0.79

£0.95

Valve plate ass'y SAC32775B.P63 Spare Part Image

SAC32775B.P63

Valve plate ass'y

Name: Valve plate ass'y

Model No: SAC32775B.P63

£69.29

£83.15

Bung (tap end of tank for 3/4" tap) SAC7085390000 Spare Part Image

SAC7085390000

Bung (tap end of tank for 3/4" tap)

Name: Bung (tap end of tank for 3/4" tap)

Model No: SAC7085390000

£56.79

£68.15

Ball valve 3/4"bsp male-3/4"bsp female SAC7130460000 Spare Part Image

SAC7130460000

Ball valve 3/4"bsp male-3/4"bsp female

Name: Ball valve 3/4"bsp male-3/4"bsp female

Model No: SAC7130460000

£79.49

£95.39

Socket Cap Bolt  M10 X 45mm
 SCB1045.S Spare Part Image

SCB1045.S

Socket Cap Bolt M10 X 45mm

Name: Socket Cap Bolt M10 X 45mm

Model No: SCB1045.S

£0.99

£1.19

Socket Cap Bolt M5 x 12mm Black SCB512.SB Spare Part Image

SCB512.SB

Socket Cap Bolt M5 x 12mm Black

Name: Socket Cap Bolt M5 x 12mm Black

Model No: SCB512.SB

£0.99

£1.19

Bolt m5x12 SM1310.60 Spare Part Image

SM1310.60

Bolt m5x12

Name: Bolt m5x12

Model No: SM1310.60

£1.79

£2.15

Spring Washer M5 Black SWM5.SB Spare Part Image

SWM5.SB

Spring Washer M5 Black

Name: Spring Washer M5 Black

Model No: SWM5.SB

£0.49

£0.59

V-belt (id-1800) b74 V/B74 Spare Part Image

V/B74

V-belt (id-1800) b74

Name: V-belt (id-1800) b74

Model No: V/B74

£30.79

£36.95

  • Air Displacement: 29.7cfm(840L/min).
  • Maximum Free Air Delivery: 26.2cfm(742L/min).
  • Maximum Pressure: 145psi(10bar).
  • Heavy-duty 3-phase compressor suitable for the professional workshop.
  • Triple cylinder pump system coupled with a 7.5hp motor maximizes performance to keep running costs low compared to single stage, single phase models.
  • Pump features heavy-duty full cast cylinders, capped by alloy heads for improved heat dissipation and long-life.
  • Heavy-duty drive guards protect belt and flywheel that is designed to force air over the pump to aid cooling.
  • Supplied with full CE certification, test certificates and operating/maintenance manual.
  • Includes a drain valve for easy release of condensed water build-up in the tank.
  • 3 Year guarantee*.
  • This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.

Air Displacement cfm(L/min):

29.7(840)

Maximum Free Air Delivery cfm(L/min):

26.2(742)

Maximum Pressure:

145psi(10bar)

Minimum Rated Supply:

32A

Motor Output:

7.5hp

Nett Weight:

193kg

Oil Capacity:

1.7L

Outlet:

1/2"BSP

Phase:

3ph

Receiver Capacity:

270L

Size (W x D x H):

1500 x 620 x 1080mm

Speed:

970rpm

Supply:

415V/32A
