Description
• HEAT OUTPUT - 20kW/68,000Btu/hr ideal for heating large areas.
• 100% HOT CLEAN AIR - Heater blows out 100% clean, fume-free warm air, so it is safe for heating indoor and poorly ventilated spaces.
• FLUE EXHAUST - Combustion by-products are exhausted out of the top of the heater. Sections of ducting and a flue system with rain cover is available separately, Model No's. ABI1000AK1, AB1000AK2, ABI1000AK3, ABI1000AK4.
•
• THERMOSTAT - Allows you to set a required ambient temperature within the space as well as measuring actual ambient temperature. The thermostat will switch the heater on and off as required in order to maintain the set temperature. As well as having an automatic shutoff feature for added safety.
• ROBUST DESIGN - Built to perform in challenging areas.
• HIGH QUALITY FEATURES - Includes a stainless steel combustion chamber with fan cooling, built-in flame sensor, Danfoss pump, electronic flame control and electronic control panel.
• 100% HOT CLEAN AIR - Heater blows out 100% clean, fume-free warm air, so it is safe for heating indoor and poorly ventilated spaces.
• FLUE EXHAUST - Combustion by-products are exhausted out of the top of the heater. Sections of ducting and a flue system with rain cover is available separately, Model No's. ABI1000AK1, AB1000AK2, ABI1000AK3, ABI1000AK4.
•
• THERMOSTAT - Allows you to set a required ambient temperature within the space as well as measuring actual ambient temperature. The thermostat will switch the heater on and off as required in order to maintain the set temperature. As well as having an automatic shutoff feature for added safety.
• ROBUST DESIGN - Built to perform in challenging areas.
• HIGH QUALITY FEATURES - Includes a stainless steel combustion chamber with fan cooling, built-in flame sensor, Danfoss pump, electronic flame control and electronic control panel.
Spare Parts
Specification & Documents
Specification
| Heat Output: | 20KW |
| Nominal Heat Output: | 20KW |
| Gross Calorific Value: | 72MJ/hr |
| IP Rating: | IPX4 |
| Fuel Consumption: | 1.65kg/hr |
| Air flow: | |
| Fuel Tank size: | 38L |
| Pump Pressure: | 0.38bar |
| Cable length: | 1.6m |
Motor Power: |
230W |
Output: |
68,242Btu/hr(20kW)
|
Running Time per Filling (Maximum): |
19hr |
Supply: |
230V ~ 50Hz |
Transport Wheels: |
Yes |
Nett Weight: |
21.3kg |
Heated Area: |
13,000ft³/375m³ (150-200m²) |
Fuel: |
Kerosene/Diesel |
Fuel Tank: |
38L |
Automatic Shut-Off: |
Yes |
Airflow: |
600m³/hr |
Energy Rating: |
A |
Barcode: |
5054630607684 |
Declaration of Conformity: |
|
Instructions: |
|
Parts Diagram: |
|
Plug Type: |
3-Pin |
