Description
• SPACE SAVING - Vertical tank saves floor space which makes it perfect for small workshops.
• OIL FREE - The benefits of oil free compressors include: Easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
• AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
• ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• PERFECT FOR WORKSHOPS - Suitable for all general-purpose workshop applications.
• OIL FREE - The benefits of oil free compressors include: Easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
• AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
• ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• PERFECT FOR WORKSHOPS - Suitable for all general-purpose workshop applications.
Specification & Documents
Noise Level: |
86dB(A)
|
Oil Capacity: |
N/A |
Outlet: |
Quick Release Coupling
|
Phase: |
1ph |
Receiver Capacity: |
24L |
Size (W x D x H): |
490 x 490 x 520mm |
Speed: |
2800rpm |
Supply: |
230V/13A |
Nett Weight: |
22.36kg |
Motor Output: |
2hp |
Minimum Rated Supply: |
230V ~ 50Hz |
Maximum Pressure: |
116psi(8bar) |
Maximum Free Air Delivery cfm(L/min): |
3.3(93)
|
Air Displacement cfm(L/min): |
6.04(171)
|
Barcode: |
5054630609312 |
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
