Description
• POWERFUL - Heavy-duty single phase 900W motor.
• HYDRAULIC DAMPING - Saw arm fitted with hydraulic damping to prevent the arm being dropped onto the workpiece and to ensure smooth cutting performance.
• LARGE CUTTING CAPACITY - Up to 210mm (in height) depending on profile (See full specification for details).
• COOLANT SYSTEM - Prolongs blade life and makes cutting smoother and more precise.
• PIVOTING BOW - Bow rotates up to 60° angle allowing supported workpiece to always sit in a central position.
• SHUT-OFF OPTIONS - Features auto and manual shut-off switches, giving the user control options when in use.
• NB - This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
• HYDRAULIC DAMPING - Saw arm fitted with hydraulic damping to prevent the arm being dropped onto the workpiece and to ensure smooth cutting performance.
• LARGE CUTTING CAPACITY - Up to 210mm (in height) depending on profile (See full specification for details).
• COOLANT SYSTEM - Prolongs blade life and makes cutting smoother and more precise.
• PIVOTING BOW - Bow rotates up to 60° angle allowing supported workpiece to always sit in a central position.
• SHUT-OFF OPTIONS - Features auto and manual shut-off switches, giving the user control options when in use.
• NB - This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Spare Parts
Specification & Documents
Specification
| Capacity 60° - Round: | Ø70mm |
| Capacity 60° - Square: | 60mm |
| Capacity 45° - Round: | Ø120mm |
| Capacity 45° - Square: | 110mm |
| Capacity 0° - Square: | 140mm |
| Capacity 0° - Round: | Ø170mm |
| Capacity 0° - Rectangle (H x W): | 210 x 140mm |
| Blade Size: | 2105 x 20 x 0.9mm |
| Blade Speed: | 80m/min |
| Coolant Pump Power: | 25W |
| Motor Power: | 900W |
| Supply: | 230V 50Hz |
| Overall Size (W x D x H): | 1500 x 800 x 1620mm |
| Weight: | 164kg |
Nett Weight: |
164kg |
Barcode: |
5054630452185 |
Declaration of Conformity: |
|
Parts Diagram: |
|
Instructions: |
