Description
• FULLY ELECTRONIC SMART CHARGER - Microprocessor controlled charger with up to ten analysis and charge phases, including trickle/maintenance.
• SUITABLE FOR – Suitable for charging 6V, 12V and 24V electrical systems and jump starting 12/24V vehicles.
• BATTERY COMPATIBILITY - Suitable for charging VRLA, GEL, AGM/EFB, Leisure and Lithium batteries (12V only).
• HIGH-POWER OUTPUT – Delivers up to 20A boost charge with timed safety cycles for fast charging and 200A starting power for 12/24V vehicles.
• WIDE CAPACITY RANGE – Suitable for batteries from 15Ah to 350Ah and maintains all sizes.
• BATTERY SUPPORT UNITS - BSU mode provides support for the battery during prolonged electronic diagnostic checks.
• ALTERNATOR TESTER – Built-in alternator check and dedicated repair function.
• SAFETY FEATURES - Integrated thermal management system, reverse polarity, short circuit, overcharge and overcurrent protection systems.
• SUITABLE FOR – Suitable for charging 6V, 12V and 24V electrical systems and jump starting 12/24V vehicles.
• BATTERY COMPATIBILITY - Suitable for charging VRLA, GEL, AGM/EFB, Leisure and Lithium batteries (12V only).
• HIGH-POWER OUTPUT – Delivers up to 20A boost charge with timed safety cycles for fast charging and 200A starting power for 12/24V vehicles.
• WIDE CAPACITY RANGE – Suitable for batteries from 15Ah to 350Ah and maintains all sizes.
• BATTERY SUPPORT UNITS - BSU mode provides support for the battery during prolonged electronic diagnostic checks.
• ALTERNATOR TESTER – Built-in alternator check and dedicated repair function.
• SAFETY FEATURES - Integrated thermal management system, reverse polarity, short circuit, overcharge and overcurrent protection systems.
Spare Parts
Specification & Documents
Specification
| Output: | 6/12/24V |
| Zero Volt Charging: | > 1V |
| Battery Support / DC Supply Mode: | Yes |
| Supply Current (Amps): | 15A |
| Supply Voltage: | 230V ~ 50Hz |
| Charger Type: | HF |
| Battery Range: (Ah) | 15-350Ah |
| Max Size Battery (Ah) Full Charge in 12hrs | 100A |
| Output Charge Peak: | 20A |
| Output Start Peak: | 200A |
| Type of Battery | All types 6V/12V/24V Lead-Acid Batteries and 12V Lithium Batteries |
| VRLA (Lead-Acid) | Yes |
| Gel | Yes |
| Lithium | Yes |
| Leisure (Deep Discharge) | yes |
Nett Weight: |
14.5kg |
Cable & Clamp Length: |
1.85m |
Barcode: |
5054630710797 |
