Description
• SLIM WALL DESIGN – Features an ultra slim wall-mounting design with no external unit for straightforward fitting.
• SMART WIFI CONTROL – Allows convenient operation through TUYA Smart Life app integration, also supplied with a remote control.
• ENERGY SAVING INVERTER – Maintains steady room temperature while reducing power consumption and noise.
• QUIET FAN OPERATION – Offers four fan speeds including silent mode for minimal disturbance.
• HIGH CAPACITY OUTPUT – Provides up to 3.5kW cooling and 2.9kW heating to manage varying seasonal conditions.
• SELF EVAPORATION SYSTEM – Minimises drainage in cooling mode for hassle free use.
• WATER LEVEL PROTECTION – Includes water full alarm and auto stop function for added reliability.
• DIMENSIONS (W x D x H) - 1000 x 205 x 585mm.
Spare Parts
Specification & Documents
Cooling Capacity: |
3.5KW |
Discharge Side Pressure: |
0.8/2.8MPa |
Energy Class: |
A for AC cooling, A+ for heating |
Exhaust Hose Length: |
0.45m |
Maximum Airflow: |
520m3/hr Cooling
520m3/hr Heating |
Maximum Water Extraction Rate: |
1.2L/Hr |
Power: |
1350W Cooling
815W Heating |
Refrigerant: |
R290 |
Suction Side Pressure: |
3.8MPa |
Supply: |
230v ~ 50Hz |
Nett Weight: |
44kg |
Mass: |
290g |
Global Warming Potential (Rating): |
T1 |
CO2 Equivalent: |
0.00087t |
Barcode: |
5054630723841 |
Safety Data Sheet: |
|
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
