Description
• TWIN CAPACITORS AND A CENTRIFUGAL SWITCH - Aids trouble-free start-up.
• HEAVY-DUTY FULL CAST CYLINDERS WITH ALLOY HEADS - For improved heat dissipation and long-life.
• BESPOKE CONTROL PANEL - Easy-to-use with two outlets, one regulated and one direct.
• HEAVY DUTY METAL WHEELS - Fitted with needle roller bearings and puncture proof tyres.
• HOSE REEL – Tank mounted to keep your workspace tidy.
• DRAIN VALVE - For easy release of condensed water build-up in the tank.
• 3 YEAR GUARANTEE*.
• HEAVY-DUTY FULL CAST CYLINDERS WITH ALLOY HEADS - For improved heat dissipation and long-life.
• BESPOKE CONTROL PANEL - Easy-to-use with two outlets, one regulated and one direct.
• HEAVY DUTY METAL WHEELS - Fitted with needle roller bearings and puncture proof tyres.
• HOSE REEL – Tank mounted to keep your workspace tidy.
• DRAIN VALVE - For easy release of condensed water build-up in the tank.
• 3 YEAR GUARANTEE*.
Spare Parts
Specification & Documents
Air Displacement cfm(L/min): |
13.4(380) |
Maximum Free Air Delivery cfm(L/min): |
10.9(310) |
Maximum Pressure: |
145psi(10bar) |
Minimum Rated Supply: |
16A |
Motor Output: |
3hp |
Oil Capacity: |
1L |
Outlet: |
High-Flow Quick Release Coupling |
Phase: |
1ph |
Receiver Capacity: |
150L |
Size (W x D x H): |
1210 x 600 x 970mm |
Speed: |
1243rpm |
Supply: |
230V/16A |
Nett Weight: |
89kg |
Barcode: |
5054630239021 |
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
