Description
• EASY TRANSPORTATION - Lightweight unit with carry handle and built-in cable tidy for easy manoeuvrability.
• OIL FREE - The benefits of oil free compressors include: easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
• ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and tank gauge displaying pressure.
• RELIABLE AND QUIET - Pump head directly coupled to heavy-duty universal motor for reliable and quiet operation.
• OIL FREE - The benefits of oil free compressors include: easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
• ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and tank gauge displaying pressure.
• RELIABLE AND QUIET - Pump head directly coupled to heavy-duty universal motor for reliable and quiet operation.
Spare Parts
Specification & Documents
Air Displacement cfm(L/min): |
1.7(50.4) |
Maximum Free Air Delivery cfm(L/min): |
0.81(23) |
Maximum Pressure: |
116psi(8bar) |
Minimum Rated Supply: |
13A |
Motor Output: |
0.5hp |
Noise Level: |
97dB(A |
Outlet: |
Quick Release Coupling |
Phase: |
1ph |
Receiver Capacity: |
11L |
Size (W x D x H): |
305 x 305 x 365mm |
Supply: |
230V/13A |
Nett Weight: |
8.9kg |
Barcode: |
5054630384882 |
