Description
• Air Displacement: 10.8cfm(305L/min).
• Maximum Free Air Delivery: 5.3cfm(150L/min).
• Maximum Pressure: 116psi(8bar).
• Belt driven pump with aluminium cylinders and cast iron liners for reduced weight and improved resistance to wear.
• Fitted with a 3hp motor.
• Heavy-duty drive guards protect belt and flywheel that is designed to force air over the pump to aid cooling.
• Suitable for general-purpose workshop applications.
• This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
• Maximum Free Air Delivery: 5.3cfm(150L/min).
• Maximum Pressure: 116psi(8bar).
• Belt driven pump with aluminium cylinders and cast iron liners for reduced weight and improved resistance to wear.
• Fitted with a 3hp motor.
• Heavy-duty drive guards protect belt and flywheel that is designed to force air over the pump to aid cooling.
• Suitable for general-purpose workshop applications.
• This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Spare Parts
Specification & Documents
Noise Level: |
97dB(A) |
Oil Capacity: |
3 x 0.3L |
Outlet: |
Quick release coupling |
Phase: |
1ph |
Receiver Capacity: |
150L |
Size (W x D x H): |
1300 x 510 x 815mm |
Speed: |
1000rpm |
Supply: |
230V/13A |
Nett Weight: |
88kg |
Motor Output: |
3hp |
Minimum Rated Supply: |
13A |
Maximum Pressure: |
116psi(8bar) |
Maximum Free Air Delivery cfm(L/min): |
5.3(150) |
Air Displacement cfm(L/min): |
10.8(305) |
Barcode: |
5054511895391 |
Parts Diagram: |
|
Safety Data Sheet: |
|
Declaration of Conformity: |
|
Instructions: |
