Description
• Air Displacement: 6.8cfm(193L/min).
• Maximum Free Air Delivery: 4.6cfm(130L/min).
• Maximum Pressure: 116psi(8bar).
• Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• Suitable for general-purpose workshop applications.
• Pump head directly coupled to heavy-duty induction motor for reliable and quiet operation.
• Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
• Fitted with 3-pin plug.
• Maximum Free Air Delivery: 4.6cfm(130L/min).
• Maximum Pressure: 116psi(8bar).
• Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• Suitable for general-purpose workshop applications.
• Pump head directly coupled to heavy-duty induction motor for reliable and quiet operation.
• Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
• Fitted with 3-pin plug.
Spare Parts
Specification & Documents
Air Displacement cfm(L/min): |
6.8(193) |
Maximum Free Air Delivery cfm(L/min): |
4.6(130) |
Maximum Pressure: |
116psi(8bar) |
Minimum Rated Supply: |
13A |
Motor Output: |
2hp |
Noise Level: |
96dB(A) |
Oil Capacity: |
0.27L |
Outlet: |
Quick Release Coupling |
Phase: |
1ph |
Receiver Capacity: |
50L |
Size (W x D x H): |
650 x 390 x 669mm |
Supply: |
230V/13A |
Nett Weight: |
29.0kg |
Barcode: |
5054511530605 |
Declaration of Conformity: |
|
Instructions: |
|
Parts Diagram: |
