Description
• LOW NOISE - Compressor runs at only 74dB, suitable for places where a standard compressor would disturb work or people in the vicinity.
• ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
• OIL FREE - The benefits of oil free compressors include: Easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
• RELIABLE AND QUIET - Pump head directly coupled to heavy-duty induction motor for reliable and quiet operation.
• HIGH QUALITY TANK - Precision welded receiver tank manufactured to meet Pressure Vessel Directive.
• PORTABLE - Compact compressor is suitable for use with the Sealey range of air nailers and air brushes.
• ALUMINIUM CONSTRUCTION - Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
• AUTOMATIC CUT-OUT- Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.
• OIL FREE - The benefits of oil free compressors include: Easy maintenance, reduced noise levels, better efficiency, quieter when running and no oil contamination in the air supply.
• RELIABLE AND QUIET - Pump head directly coupled to heavy-duty induction motor for reliable and quiet operation.
• HIGH QUALITY TANK - Precision welded receiver tank manufactured to meet Pressure Vessel Directive.
• PORTABLE - Compact compressor is suitable for use with the Sealey range of air nailers and air brushes.
Spare Parts
Specification & Documents
Air Displacement cfm(L/min): |
4cfm(120L/min) |
Maximum Free Air Delivery cfm(L/min): |
1.95cfm(55L/min) |
Maximum Pressure: |
116psi(8bar) |
Minimum Rated Supply: |
13A |
Motor Output: |
1hp |
Noise Level: |
74db |
Outlet: |
Quick Release Coupling |
Phase: |
1ph |
Receiver Capacity: |
6L |
Size (W x D x H): |
455 x 170 x 480mm |
Supply: |
230V/13A |
Nett Weight: |
15.1kg |
Barcode: |
5054630386213 |
Instructions: |
|
Declaration of Conformity: |
|
Parts Diagram: |
