Description
• HEAVY-DUTY HYDRAULICS - Powerful and reliable, ideal for workshop or roadside use.
• AIR OPERATED - Takes the effort out of lifting heavy plant, tractors and commercial vehicles.
• SAFETY LOCK - Dead man’s control and sectional pump handle for manual operation, when air is unavailable.
• LOWERING SYSTEM - Automatic dual spring controlled.
• OVERLOAD SAFETY VALVE - Safety valve fitted to prevent damaged to the unit.
• AIR OPERATED - Takes the effort out of lifting heavy plant, tractors and commercial vehicles.
• SAFETY LOCK - Dead man’s control and sectional pump handle for manual operation, when air is unavailable.
• LOWERING SYSTEM - Automatic dual spring controlled.
• OVERLOAD SAFETY VALVE - Safety valve fitted to prevent damaged to the unit.
Spare Parts
Specification & Documents
Air Consumption: |
7.5cfm |
Capacity: |
20 Tonne |
Chassis Length: |
169mm |
Maximum Height: |
510mm |
Minimum Height: |
260mm |
Overall Width: |
175mm |
Piston Stroke: |
170mm |
Screw Extension: |
80mm |
Nett Weight: |
11.75kg |
Working Pressure: |
109-123psi |
Barcode: |
5054630413957 |
Declaration of Conformity: |
|
Safety Data Sheet: |
|
Parts Diagram: |
|
Instructions: |
