Description
• DUAL VOLTAGE – The versatility of using either 230V or 110V by the switch of a plug.
• VERSATILE – Proven pump system can operate with either kerosene or diesel.
• HEAT OUTPUT - 185,000Btu/hr(55kW).
• CLEAN BURNING - A more thorough burn of fuel using a stainless steel combustion chamber which means greater fuel economy and maximum heating effect.
• LARGE FUEL TANK – 50L Tank operates for a maximum of 10hr on a single fill of fuel.
• THERMOSTATICALLY CONTROLLED – Dual LED display for ambient and thermostatically controlled temperature.
• SAFETY FEATURES - Fitted with a flame-out device which cuts the fuel supply when the flame is inadvertently extinguished.
• QUALITY ASSURANCE – Workshop tried and tested featuring sturdy handle and heavy-duty wheels for easy manoeuvrability.
• VERSATILE – Proven pump system can operate with either kerosene or diesel.
• HEAT OUTPUT - 185,000Btu/hr(55kW).
• CLEAN BURNING - A more thorough burn of fuel using a stainless steel combustion chamber which means greater fuel economy and maximum heating effect.
• LARGE FUEL TANK – 50L Tank operates for a maximum of 10hr on a single fill of fuel.
• THERMOSTATICALLY CONTROLLED – Dual LED display for ambient and thermostatically controlled temperature.
• SAFETY FEATURES - Fitted with a flame-out device which cuts the fuel supply when the flame is inadvertently extinguished.
• QUALITY ASSURANCE – Workshop tried and tested featuring sturdy handle and heavy-duty wheels for easy manoeuvrability.
Spare Parts
Specification & Documents
Specification
| Net Dimensions (W x D X H) inc Wheels & Handle: | 1076 x 515 x 645mm |
| Fuel Consumption: | 4.3kg/hr |
| Max air output: | 1100m³/hr |
| Current: | 1.2/2.6A |
| Airflow: | 1100m³ |
| Outlet: | 2.4m |
| Side,Top and Rear: | 1.2m |
Automatic Shut-Off: |
Yes |
Fuel Tank: |
50L |
Fuel: |
Kerosene/Diesel |
Heated Area: |
55,000ft³(1500m³), 500-720m³ |
Motor Power: |
290W using 230V
270W using 110V
290W/270W |
Output: |
185,000Btu/hr(55kW) |
Running Time per Filling (Maximum): |
10hr-4.3kg/hr |
Supply: |
230v ~ 50hz or 110V ~ 50Hz |
Nett Weight: |
22.8kg |
Barcode: |
5054630550607 |
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
