Description
• REINFORCED - Steel drum is reinforced to make the product strong and durable.
• WEATHERPROOF - Rated IP68 this winch will withstand any weather conditions.
• 3-STAGE PLANETARY GEARS - Increased pull generated by the gear train.
• 2-BRAKE SYSTEM - Mechanical cone brake and a permanent motor dynamic brake work together to keep the load stable and protect the user.
• WIRE LENGTH - 18m.
• MOTOR - Permanent magnet motor 12V - 1.6HP/1.2KW.
• MAXIMUM WEIGHT - 450kg(1000lbs).
• WEATHERPROOF - Rated IP68 this winch will withstand any weather conditions.
• 3-STAGE PLANETARY GEARS - Increased pull generated by the gear train.
• 2-BRAKE SYSTEM - Mechanical cone brake and a permanent motor dynamic brake work together to keep the load stable and protect the user.
• WIRE LENGTH - 18m.
• MOTOR - Permanent magnet motor 12V - 1.6HP/1.2KW.
• MAXIMUM WEIGHT - 450kg(1000lbs).
Spare Parts
Specification & Documents
Specification
| Specification: | |
| Min. Breaking Rope Force: | 4500lbs (2040kg) |
| Max. Rope Diameter: | Ø5.4mm |
| Max. No. of Rope Winding Layers: | 4 (Always Keep Working on First Layer) |
Current Draw: |
12V Full Load - 75A |
Gear Ratio: |
140:1 |
Line Pull*: |
454kg 1000lbs |
Line Speed*: |
Full Load - 3.8m/min |
Motor Power: |
12V - 1200W |
Nett Weight: |
11kg |
Wire Rope Diameter: |
Ø4.8mm |
Wire Rope Length: |
18.3m |
Rated Capacity: |
454kg 1000lbs |
Barcode: |
5054630632662 |
