Description
• Made from high quality steel with a powder coated paint finish to help corrosion resistance.
• Detachable pump and ram allowing hydraulics to be used for other purposes when press is not in use.
• Includes 2 table plates.
• Supplied with gauge.
• Detachable pump and ram allowing hydraulics to be used for other purposes when press is not in use.
• Includes 2 table plates.
• Supplied with gauge.
Spare Parts
Specification & Documents
Bench or Floor Mounting: |
Floor |
Capacity: |
10 Tonne |
Gauge Included: |
Yes |
Lateral Ram Travel: |
n/a |
Maximum Height - Ram to Table: |
917mm |
Minimum Height - Ram to Table: |
77mm |
Optional Accessories: |
n/a |
Overall Height: |
1657mm |
Ram Diameter: |
Ø40mm |
Ram Stroke: |
175mm |
Screw Extension: |
n/a |
Table Aperture: |
84mm |
Type: |
Hydraulic |
Nett Weight: |
66.5kg |
Working Table Depth: |
180mm |
Working Table Width: |
590mm |
Barcode: |
5054511703443 |
