Description
• VERSATILE - Ideal for use in well-ventilated indoor areas including garages, workshops, warehouses, and marquees.
• INFRARED TECHNOLOGY – Infrared technology heater has no electric fan, meaning there is no air movement, and the heat is spread evenly in all directions, quietly and dust-free.
• COST EFFECTIVE – inexpensive to run, using only around 1.5L of fuel per hour.
• CLEAN BURN – A controlled fuel supply ensures that no unpleasant odours or carbon monoxide enter the air.
• SAFETY - Equipped with advanced safety features including overheat protection, auto-misfire, tilt, shock, low fuel shut-off sensors and flame-out fuel cut.
• TIMER - Soft-touch control panel with LED display and 24hr Timer using a temperature control thermostat.
• MANOEUVRABILITY – Supplied with four castor wheels for easy movement around the workspace.
• EXTENSION EXHAUST - Stainless exhaust available as an extra - IREX1 (End Pipe), IREX2 (1m Extension), IREX3 (90° Bend).
• 3 YEAR GUARANTEE*.
• INFRARED TECHNOLOGY – Infrared technology heater has no electric fan, meaning there is no air movement, and the heat is spread evenly in all directions, quietly and dust-free.
• COST EFFECTIVE – inexpensive to run, using only around 1.5L of fuel per hour.
• CLEAN BURN – A controlled fuel supply ensures that no unpleasant odours or carbon monoxide enter the air.
• SAFETY - Equipped with advanced safety features including overheat protection, auto-misfire, tilt, shock, low fuel shut-off sensors and flame-out fuel cut.
• TIMER - Soft-touch control panel with LED display and 24hr Timer using a temperature control thermostat.
• MANOEUVRABILITY – Supplied with four castor wheels for easy movement around the workspace.
• EXTENSION EXHAUST - Stainless exhaust available as an extra - IREX1 (End Pipe), IREX2 (1m Extension), IREX3 (90° Bend).
• 3 YEAR GUARANTEE*.
Spare Parts
Specification & Documents
Specification
| Power: | 80W |
| Energy Efficiency Class: | A |
| Noise Level: | 58dB(A) |
| Nominal Heat Output: | 20kW |
| Energy Efficiency Index: | 92% |
| Useful Energy Efficiency at Nominal Heat Output: ⴄ (nom): | 88.85% |
Automatic Shut-Off: |
Yes |
Fuel Tank: |
70L |
Fuel: |
Diesel |
Heated Area: |
14,740ft³(450m³) |
Motor Power: |
80W |
Output: |
64,000btu/hr(19kW) |
Running Time per Filling (Maximum): |
36hr |
Supply: |
230V~50Hz |
Transport Wheels: |
Yes |
Nett Weight: |
57kg |
Energy Rating: |
A |
Barcode: |
5054630630934 |
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
