Description
• Complies with the requirements of the Machinery Safety Directive and full CE approved.
• Fully guarded blade with magnetic no-load voltage switch to prevent motor restart in the event of power failure or blade jam.
• Fitted with oil-bath gearbox and life lubricated drive bearings for quiet, smooth operation.
• 3-Speed settings.
• Heavy-duty cast base and horizontal/vertical cutting arm.
• Saw base features integral mitring vice with scale of 45° to 90° for angle cutting and fully adjustable precision blade guides for accurate cutting and longer blade life.
• Stand is fitted with two wheels.
• Fully guarded blade with magnetic no-load voltage switch to prevent motor restart in the event of power failure or blade jam.
• Fitted with oil-bath gearbox and life lubricated drive bearings for quiet, smooth operation.
• 3-Speed settings.
• Heavy-duty cast base and horizontal/vertical cutting arm.
• Saw base features integral mitring vice with scale of 45° to 90° for angle cutting and fully adjustable precision blade guides for accurate cutting and longer blade life.
• Stand is fitted with two wheels.
Spare Parts
Specification & Documents
Specification
| Capacity 90º - Round: | Ø115mm |
| Capacity 90º - Square/Rectangular (H x W): | 100 x 150mm |
| Capacity 45º - Round: | Ø60mm |
| Capacity 45º - Square/Rectangular (H x W): | 100 x 60mm |
| Blade Size: | 1638 x 13 x 0.63mm |
| Blade Speeds: | 18, 30, 48m/min |
| Motor Power: | 375W |
| Supply: | 230V |
| Weight: | 60kg |
Nett Weight: |
60kg |
Barcode: |
5024209205818 |
Declaration of Conformity: |
|
Parts Diagram: |
|
Instructions: |
