Description
• Bench mounting multifunction mini drill, mill and lathe with variable speed giving flexibility to handle most materials.
• Features two 150W motors, one to operate the drill/mill and the other to power the lathe.
• The lathe cutting feed can be power driven or advanced manually.
• Thread cutting may also be undertaken with the optional thread cutting kit.
• Supplied with Metric graduated scales and all necessary tools required for setting and adjusting.
• An optional stand is available, order Model No. SM3002ST.
• Features two 150W motors, one to operate the drill/mill and the other to power the lathe.
• The lathe cutting feed can be power driven or advanced manually.
• Thread cutting may also be undertaken with the optional thread cutting kit.
• Supplied with Metric graduated scales and all necessary tools required for setting and adjusting.
• An optional stand is available, order Model No. SM3002ST.
Spare Parts
Specification & Documents
Specification
| Specification - Cutting: | |
| Swing Over Bed: | 140mm |
| Distance Between Centres: | 250mm |
| Spindle Hole Taper: | MT2 |
| Cross Slide Travel: | 61mm |
| Tailstock Taper: | MT1 |
| Spindle Speed (Variable): | 100-2000rpm |
| Range of Metric Threads: | 5 Pitches (0.5-1.25mm) |
| Specification - Drilling: | |
| Maximum Drilling/Milling Capacity: | 10mm |
| Drilling/Milling Spindle Travel: | 30mm |
| Drilling/Milling Spindle Speed: | 100-1300rpm |
| T-Slot: | 8mm |
| Distance from Spindle to Table: | 180mm |
| Distance from Spindle Centre to Column: | 100mm |
| Motor Power: | 2 x 150W - 230V |
| Weight: | 39.2kg |
Nett Weight: |
39.2kg |
Barcode: |
5024209625852 |
Declaration of Conformity: |
|
Instructions: |
|
Parts Diagram: |
