Description
• INTERNAL COMPRESSOR - Features an integral compressor reducing the need for a secondary unit yet still lightweight weighing only 18.5kg.
• IGBT INVERTER – Inverter power supply fitted with plasma cutter control circuitry.
• SUPPLIED WITH- Supplied with built-in 4m plasma torch, earth cable and 4m gas hose.
• CLEAR LED DISPLAY – Easy to read LED display to show the current output and dial adjustment from 15-40A.
• CAN BE USED NEAR ELECTRICAL EQUIPMENT - Uses air to strike arc making it suitable for use near electrical equipment.
• SUITABLE FOR MOST METALS - Ideal for cutting steel, stainless, galvanized steel, aluminium, copper and brass.
• IGBT INVERTER – Inverter power supply fitted with plasma cutter control circuitry.
• SUPPLIED WITH- Supplied with built-in 4m plasma torch, earth cable and 4m gas hose.
• CLEAR LED DISPLAY – Easy to read LED display to show the current output and dial adjustment from 15-40A.
• CAN BE USED NEAR ELECTRICAL EQUIPMENT - Uses air to strike arc making it suitable for use near electrical equipment.
• SUITABLE FOR MOST METALS - Ideal for cutting steel, stainless, galvanized steel, aluminium, copper and brass.
Spare Parts
Specification & Documents
Specification
| Power Output: | 15-40A |
| Duty Cycle: | 20% @ 40A 30% @ 35A , 60% @ 25A |
| Max Cutting Thickness: | 10mm |
| Air Requirements: | Integral Compressor. |
| Air Pressure: | N/A |
| Absorbed Power: | 6.9kw |
| Supply: | 230V |
| Insualtion: | F |
| Protection: | IP21S |
| Nett Weight: | 18.5kg |
| Accessories: | Yes |
| Replacement Consumables: | |
| Electrode, Short (Pack of 5): | PP40PLUS.E (x5) |
| Nozzle, Short (Pack of 5): | PP40PLUS.N (x5) |
| Diffuser (Pack of 5): | PP40PLUS.D (x5) |
| Safety Cap (Pack of 2): | PP40PLUS.SC (x2) |
| Note: | *To achieve maximum power a 32A supply may be required. |
Nett Weight: |
18.5kg |
Barcode: |
5054630440892 |
Instructions: |
|
Parts Diagram: |
|
Declaration of Conformity: |
