Description
• CERTIFIED - Approved to EU and UK Lifting Gear Regulations.
• POWERFUL AND SAFE - Fitted with a powerful 750W motor with a thermal overload switch.
• REMOTE CONTROL - Due to the remote control, the hoist can be operated easily, and from a safe distance.
• AUTO-STOP - Fitted with an automatic system to stop the unit at it's full lift height.
• SIMPLE INSTALLATION - Two mounting brackets are included, to easily install the hoist to a suitable support arm. (The support bar is not included.)
• POWERFUL AND SAFE - Fitted with a powerful 750W motor with a thermal overload switch.
• REMOTE CONTROL - Due to the remote control, the hoist can be operated easily, and from a safe distance.
• AUTO-STOP - Fitted with an automatic system to stop the unit at it's full lift height.
• SIMPLE INSTALLATION - Two mounting brackets are included, to easily install the hoist to a suitable support arm. (The support bar is not included.)
Spare Parts
Specification & Documents
Capacity (Double Cable): |
400kg |
Capacity (Single Cable): |
200kg |
Current: |
3.3A |
Lift Speed (Maximum): |
8m/min |
Group of Mechanisms: |
M1 |
Insulating Grade: |
B |
IP Rating: |
IP54 |
Lift Height (Double Cable): |
6m |
Lift Height (Single Cable): |
12m |
Minimum Rope Tensile Strength: |
1770N/mm² |
Motor Power: |
750W |
Rope Diameter: |
Ø3.8mm |
Voltage: |
230V~50Hz |
Nett Weight: |
32.5kg |
Work Rate: |
S3 |
Barcode: |
5054630617584 |
Duty Cycle: |
S3 |
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
