Description
• Steel chassis with locking blade wheel covers.
• Bearing-mounted blade wheels and belt drive induction motor provide smooth operation.
• Micro switches prevent operation when either blade wheel cover is open.
• No-volt release switch prevents uncontrolled blade restart after power interruption.
• 2-Speed operation enables bandsaw to cut multiple types of materials.
• Suitable for cutting wood and plastics.
• Fitted with tilting table for cutting compound mitres.
• Supplied with quick adjusting rip fence, mitre gauge, dust extraction port and sturdy metal stand.
• Throat Depth: 335mm.
• Maximum Cutting Height: 165mm.
• Ø100mm Dust extraction port.
• This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Spare Parts
Specification & Documents
Blade Length: |
2400mm |
Cutting Speed: |
540, 660m/min |
Dust Extraction Diameter: |
Ø100mm |
Maximum Cutting Height: |
165mm |
Motor Power: |
750W |
Supply: |
230V |
Table Size: |
500 x 400mm |
Table Tilt: |
0-45° |
Throat Depth: |
335mm |
Nett Weight: |
93.35kg |
Barcode: |
5024209851831 |
Declaration of Conformity: |
|
Instructions: |
|
Parts Diagram: |
