Description
• Manufactured from heavy-duty steel with a powder coated finish for added corrosion resistance.
• Features a unique 360° swivel base for easy rotation.
• Threaded locking arm allows the crane to be locked in place when not in use.
• Mounts easily onto any strong and stable surface including loading bays, 4x4s, flatbed trucks and trailers.
• Robust lifting ram enables a maximum capacity of 750kg when the lifting boom is retracted and 250kg when fully extended.
• Includes heavy-duty chain and hook.
• Hook features safety clip to help prevent load sling from slipping.
• Features a unique 360° swivel base for easy rotation.
• Threaded locking arm allows the crane to be locked in place when not in use.
• Mounts easily onto any strong and stable surface including loading bays, 4x4s, flatbed trucks and trailers.
• Robust lifting ram enables a maximum capacity of 750kg when the lifting boom is retracted and 250kg when fully extended.
• Includes heavy-duty chain and hook.
• Hook features safety clip to help prevent load sling from slipping.
Spare Parts
Specification & Documents
Specification
Height Jib Down: |
1530mm |
Height Legs Folded: |
n/a |
Height of Frame: |
n/a |
Length Legs Extended: |
n/a |
Length of Jib Position 1: |
825mm
|
Length of Jib Position 2: |
1180mm
|
Length of Jib Position 3: |
n/a
|
Length of Jib Position 4: |
n/a |
Length of Jib Position 5: |
n/a |
Length: |
n/a
|
Lifting Capacity in Position 1: |
750kg |
Lifting Capacity in Position 2: |
250kg
|
Lifting Capacity in Position 3: |
n/a
|
Lifting Capacity in Position 4: |
n/a
|
Lifting Capacity in Position 5: |
n/a
|
Max. Lift Ht at Jib Position 1: |
2060mm
|
Max. Lift Ht at Jib Position 2: |
2350mm |
Max. Lift Ht at Jib Position 3: |
n/a
|
Max. Lift Ht at Jib Position 4: |
n/a
|
Max. Lift Ht at Jib Position 5: |
n/a
|
Rear Width: |
n/a
|
Nett Weight: |
49kg
|
Width Front Frame: |
n/a
|
Width Inside Front Frame: |
n/a
|
Barcode: |
5054630285295 |
Parts Diagram: |
|
Declaration of Conformity: |
|
Instructions: |
|
Safety Data Sheet: |
