Description
• DUAL POWER – The unit can run from both mains power 230V AC and 12V plug for use in vehicle accessory power socket.
• 3 MINUTE INFLATION TIME – Inflates any Schrader valve on cars, vans, 4x4s, motorcycles and bicycles.
• HIGH VOLUME AIR PUMP – Inflate and deflate function, for fast inflation of air mattresses and inflatables providing a maximum inflation rate of 350L/min.
• EASY OPERATION - Works in four pressure units: psi, kPa, kg/cm² and bar with maximum pressure of 120psi.
• BACKLIT DISPLAY SCREEN – Easy-to-read large digital display screen.
• AUTO-SHUT-OFF – Unit features auto-shut-off when preset pressure is reached.
• COMPACT UNIT – Lightweight unit for easy transportability with accessories fixed to the housing for easy storage, with anti-vibration feet.
• WITH ACCESSORIES – Schrader connection, Presta type adaptor, ball spike and inflatable adaptor.
• INTEGRATED LED LIGHT – White SMD LED worklight with red SOS and red flashing light function.
• 3 MINUTE INFLATION TIME – Inflates any Schrader valve on cars, vans, 4x4s, motorcycles and bicycles.
• HIGH VOLUME AIR PUMP – Inflate and deflate function, for fast inflation of air mattresses and inflatables providing a maximum inflation rate of 350L/min.
• EASY OPERATION - Works in four pressure units: psi, kPa, kg/cm² and bar with maximum pressure of 120psi.
• BACKLIT DISPLAY SCREEN – Easy-to-read large digital display screen.
• AUTO-SHUT-OFF – Unit features auto-shut-off when preset pressure is reached.
• COMPACT UNIT – Lightweight unit for easy transportability with accessories fixed to the housing for easy storage, with anti-vibration feet.
• WITH ACCESSORIES – Schrader connection, Presta type adaptor, ball spike and inflatable adaptor.
• INTEGRATED LED LIGHT – White SMD LED worklight with red SOS and red flashing light function.
Spare Parts
Specification & Documents
Specification
| Airflow: | Compressor: 22L/min High Volume Air Pump: 350L/min |
| Hose Length: | 700mm |
| Maximum Pressure: | 120psi |
| High Volume Hose Length: | 400mm |
| Supply: | 230V~50Hz or 12V-10A |
| Power Supply Cable: | AC: 1.8m DC: 3m |
| Continuous Working Time: | 30mins |
| LED Light: | 3 Modes |
| Inflation Time (175/70/R13): | 0-30psi in 194sec (230V) 0-30psi in 226sec (12V) |
| Max Current: | 10A |
| Power: | 120W |
| Max. Air Output: | 120psi(8.3bar) |
| High Pressure Hose Length: | 640mm |
Accuracy: |
±1%
|
Maximum Air Supply: |
120psi(8.3bar) |
Pressure Units: |
psi, kPa, kg/cm², bar |
Range: |
0-120psi |
Nett Weight: |
1.495kg
|
Barcode: |
5054630527128 |
Declaration of Conformity: |
|
Instructions: |
