Description
• LONG REACH - Provides easy access to deep-set jacking points.
• LIFTING RANGE - Minimum saddle height 150mm, maximum saddle height 650mm.
• AIR OPERATED CONTROLS - Ideal for workshop or roadside use, takes the effort out of lifting heavy plant, tractors and commercial vehicles.
• ROCKET LIFT - Brings the lifting arm straight into contact with the jacking point in minimal strokes.
• SAFETY RELEASE - Handle mounted safety release, prevents inadvertent lowering.
• LARGE SADDLE - Includes large diameter saddle for easier positioning under the jacking point.
• DAMAGE PREVENTING JACK PAD - Rubber jack pad to prevent damage to the underside of the vehicle's jacking point.
• HEAVY ITEM - Extra assistance must be provided at the delivery point to help its safe delivery.
• EXTENDED WARRANTY - 3 YEAR GUARANTEE*.
• LIFTING RANGE - Minimum saddle height 150mm, maximum saddle height 650mm.
• AIR OPERATED CONTROLS - Ideal for workshop or roadside use, takes the effort out of lifting heavy plant, tractors and commercial vehicles.
• ROCKET LIFT - Brings the lifting arm straight into contact with the jacking point in minimal strokes.
• SAFETY RELEASE - Handle mounted safety release, prevents inadvertent lowering.
• LARGE SADDLE - Includes large diameter saddle for easier positioning under the jacking point.
• DAMAGE PREVENTING JACK PAD - Rubber jack pad to prevent damage to the underside of the vehicle's jacking point.
• HEAVY ITEM - Extra assistance must be provided at the delivery point to help its safe delivery.
• EXTENDED WARRANTY - 3 YEAR GUARANTEE*.
Spare Parts
Specification & Documents
Specification
| Min Air pressure | 110psi |
| Max air pressure | 120psi |
Capacity: |
6 Tonne |
Length: |
1390mm |
Maximum Chassis Height: |
189mm |
Maximum Saddle Height: |
650mm |
Minimum Saddle Height: |
150mm |
Nett Weight: |
85.8kg |
Barcode: |
5054630636653 |
Declaration of Conformity: |
|
Safety Data Sheet: |
|
Parts Diagram: |
|
Instructions: |
