Description
• Max. Charge: 30A(20A EN).
• Max. Start: 160A(140A EN).
• 12/24V Output.
• Battery Range: 15-300Ah.
• Combination unit capable of both charging batteries and providing boost power to help start vehicles with flat batteries.
• Model features easy-to-read ammeters and illuminated power switches.
• Circuitry is protected by a panel mounted fuse.
• Suitable for fleet operators running cars and van derivatives.
• Built-in polarity protection.
• Max. Start: 160A(140A EN).
• 12/24V Output.
• Battery Range: 15-300Ah.
• Combination unit capable of both charging batteries and providing boost power to help start vehicles with flat batteries.
• Model features easy-to-read ammeters and illuminated power switches.
• Circuitry is protected by a panel mounted fuse.
• Suitable for fleet operators running cars and van derivatives.
• Built-in polarity protection.
Spare Parts
Specification & Documents
Specification
| Output: | 12/24V |
| Output Charge Peak(EN): | 30A(20A) |
| Output Start Peak(EN): | 160A(140A) |
| Battery Range: | 15-300Ah |
| Input Charge: | 3.5A |
| Input Start: | 12.5A |
| Charging Rates: | 3 |
| Supply: | 230V |
| Polarity Protection: | Fuse (1 x 80A) |
| Fuse: | 120/802260 (Pack of 20) 120/122351 (Single) |
Cable & Clamp Length: |
2m |
Nett Weight: |
9.00kg |
Barcode: |
5024209213783 |
Declaration of Conformity: |
|
Parts Diagram: |
|
Instructions: |
