Description
• ALUMINIUM CYLINDER HEAD AND CAST IRON CYLINDER – Gives added resistance to wear for improved product life.
• 110V - Suitable for on site applications or anywhere that requires 110V. Especially useful for mandatory tyre pressure checks on site vehicles.
• TWIN GAUGES – One displays the tank pressure and the other displays the working pressures.
• MULTIFUNCTION – Able to inflate and deflate tyres.
• BRASS BLEED BUTTON – Useful when deflating an over pumped tyre.
• ORGANISED – Polyurethane recoil type hose helps to keep working area tidy and free of hoses when not in use.
• Package includes:
• Model No. - Description
• SAC2420E110V - Air Compressor 24L Direct Drive 2hp 110V
• SA332 - Tyre Inflator with Gauge
• ATO1000S - Air Tool Oil 1L
• AH10C/8 - PU Coiled Air Hose 10m x Ø8mm with 1/4"BSP Unions
• ACX90 - Screwed Swivel Adaptor Male 1/4"BSPT
• 110V - Suitable for on site applications or anywhere that requires 110V. Especially useful for mandatory tyre pressure checks on site vehicles.
• TWIN GAUGES – One displays the tank pressure and the other displays the working pressures.
• MULTIFUNCTION – Able to inflate and deflate tyres.
• BRASS BLEED BUTTON – Useful when deflating an over pumped tyre.
• ORGANISED – Polyurethane recoil type hose helps to keep working area tidy and free of hoses when not in use.
• Package includes:
• Model No. - Description
• SAC2420E110V - Air Compressor 24L Direct Drive 2hp 110V
• SA332 - Tyre Inflator with Gauge
• ATO1000S - Air Tool Oil 1L
• AH10C/8 - PU Coiled Air Hose 10m x Ø8mm with 1/4"BSP Unions
• ACX90 - Screwed Swivel Adaptor Male 1/4"BSPT
Spare Parts
Specification & Documents
Air Displacement cfm(L/min): |
6.3(178) |
Maximum Free Air Delivery cfm(L/min): |
4.6(130) |
Maximum Pressure: |
116psi(8bar) |
Minimum Rated Supply: |
16A |
Motor Output: |
2hp |
Noise Level: |
95dB(A) |
Oil Capacity: |
0.27L |
Outlet: |
Quick Release Coupling |
Phase: |
1ph |
Receiver Capacity: |
24L |
Supply: |
110V/16A |
Barcode: |
5054630471803 |
