1.5 Tonne Vertical Transmission Jack | 1500TR | Sealey Sealey
Product Image Thumbnail Product Image Thumbnail
Product Image
Product Image

Vertical Transmission Jack 1.5 Tonne

Model No. 1500TR
List Price
Buy Online
Image Thumbnail Image Thumbnail
List Price

  • Manufactured to exacting standards, strong construction for durability and suitable for general workshop applications.
  • Spring loaded dead man's safety release control reduces the risk of inadvertent lowering.
  • 2-Way hydraulic unit ensures that the saddle lowers at a controlled speed at all times, even without load.
  • Extra-large castors allow for increased manoeuvrability.
  • Hydraulic unit larger than the economy models for improved performance and durability.
  • Can be fitted with Model No. ADT5 - Adjustable Gearbox Support.

Base Size:

680 x 700mm

Capacity:

1500kg

Fixed/Adjustable Saddle:

Fixed

Maximum Saddle Height:

1950mm

Minimum Saddle Height:

1120mm

Nett Weight:

51kg

Optional Accessories:

ADT5 - Adjustable Gearbox Support

Pump Strokes to Maximum Height:

n/a

Ram Extensions:

1

Model No.

Description

List Price (Exc. VAT)

List Price (Inc. VAT)

Saddle Assembly, Black Forked (F) Ø 110mm (Shaft Ø 35mm) 1500TR.01 Spare Part Image

1500TR.01

Saddle Assembly, Black Forked (F) Ø 110mm (Shaft Ø 35mm)

Name: Saddle Assembly, Black Forked (F) Ø 110mm (Shaft Ø 35mm)

Model No: 1500TR.01

£15.11

£18.13

Dust Seal 38*1 1500TR.02 Spare Part Image

1500TR.02

Dust Seal 38*1

Name: Dust Seal 38*1

Model No: 1500TR.02

£1.61

£1.93

Cylinder head ass'y 1500TR.04 Spare Part Image

1500TR.04

Cylinder head ass'y

Name: Cylinder head ass'y

Model No: 1500TR.04

£85.49

£102.59

O-ring, (Ex: 15.29 10.81 Cs: 2.24) 1500TR.06 Spare Part Image

1500TR.06

O-ring, (Ex: 15.29 10.81 Cs: 2.24)

Name: O-ring, (Ex: 15.29 10.81 Cs: 2.24)

Model No: 1500TR.06

£0.44

£0.53

Release rod 12 1500TR.07 Spare Part Image

1500TR.07

Release rod 12

Name: Release rod 12

Model No: 1500TR.07

£4.31

£5.17

Bush 1500TR.08 Spare Part Image

1500TR.08

Bush

Name: Bush

Model No: 1500TR.08

£3.41

£4.09

Spring Dia 33.2mm
 1500TR.09 Spare Part Image

1500TR.09

Spring Dia 33.2mm

Name: Spring Dia 33.2mm

Model No: 1500TR.09

£2.96

£3.55

Knob, Release, Red, Coated Steel, OD: 60mm L: 87mm, M10x18mm 1500TR.10 Spare Part Image

1500TR.10

Knob, Release, Red, Coated Steel, OD: 60mm L: 87mm, M10x18mm

Name: Knob, Release, Red, Coated Steel, OD: 60mm L: 87mm, M10x18mm

Model No: 1500TR.10

£4.49

£5.39

O-ring, (Ex: 60.43 In: 53.37 Cs: 3.53) 1500TR.13 Spare Part Image

1500TR.13

O-ring, (Ex: 60.43 In: 53.37 Cs: 3.53)

Name: O-ring, (Ex: 60.43 In: 53.37 Cs: 3.53)

Model No: 1500TR.13

£0.71

£0.85

O-ring, (Ex: 83.41 In: 77.43 Cs: 3) 1500TR.14 Spare Part Image

1500TR.14

O-ring, (Ex: 83.41 In: 77.43 Cs: 3)

Name: O-ring, (Ex: 83.41 In: 77.43 Cs: 3)

Model No: 1500TR.14

£0.89

£1.07

Oil filter plug 1500TR.15 Spare Part Image

1500TR.15

Oil filter plug

Name: Oil filter plug

Model No: 1500TR.15

£0.71

£0.85

Oil reservoir ass'y 1500TR.16 Spare Part Image

1500TR.16

Oil reservoir ass'y

Name: Oil reservoir ass'y

Model No: 1500TR.16

£47.06

£56.47

Cylinder 1500TR.17 Spare Part Image

1500TR.17

Cylinder

Name: Cylinder

Model No: 1500TR.17

£58.76

£70.51

Piston 1500TR.18 Spare Part Image

1500TR.18

Piston

Name: Piston

Model No: 1500TR.18

£118.34

£142.01

Piston screw 1500TR.19 Spare Part Image

1500TR.19

Piston screw

Name: Piston screw

Model No: 1500TR.19

£10.16

£12.19

Screw 1500TR.21 Spare Part Image

1500TR.21

Screw

Name: Screw

Model No: 1500TR.21

£0.89

£1.07

Bush 1500TR.25 Spare Part Image

1500TR.25

Bush

Name: Bush

Model No: 1500TR.25

£1.61

£1.93

Spring Dia 36.7mm
 1500TR.26 Spare Part Image

1500TR.26

Spring Dia 36.7mm

Name: Spring Dia 36.7mm

Model No: 1500TR.26

£8.36

£10.03

Pump cylinder 1500TR.27 Spare Part Image

1500TR.27

Pump cylinder

Name: Pump cylinder

Model No: 1500TR.27

£8.09

£9.71

Pump rod 1500TR.28 Spare Part Image

1500TR.28

Pump rod

Name: Pump rod

Model No: 1500TR.28

£6.29

£7.55

Cup Seal 20*12*6 1500TR.29 Spare Part Image

1500TR.29

Cup Seal 20*12*6

Name: Cup Seal 20*12*6

Model No: 1500TR.29

£3.41

£4.09

O-ring, (Ex: 26.37 In: 21.68 Cs: 2.35) 1500TR.30 Spare Part Image

1500TR.30

O-ring, (Ex: 26.37 In: 21.68 Cs: 2.35)

Name: O-ring, (Ex: 26.37 In: 21.68 Cs: 2.35)

Model No: 1500TR.30

£0.44

£0.53

Screw 1500TR.31 Spare Part Image

1500TR.31

Screw

Name: Screw

Model No: 1500TR.31

£0.44

£0.53

O-ring, (Ex: 30.79 In: 24.75 Cs: 3.02) 1500TR.32 Spare Part Image

1500TR.32

O-ring, (Ex: 30.79 In: 24.75 Cs: 3.02)

Name: O-ring, (Ex: 30.79 In: 24.75 Cs: 3.02)

Model No: 1500TR.32

£0.44

£0.53

Spring Dia 7.6mm

 1500TR.33 Spare Part Image

1500TR.33

Spring Dia 7.6mm

Name: Spring Dia 7.6mm

Model No: 1500TR.33

£0.71

£0.85

Taper valve 1500TR.34 Spare Part Image

1500TR.34

Taper valve

Name: Taper valve

Model No: 1500TR.34

£1.61

£1.93

Retaining ring 12 1500TR.35 Spare Part Image

1500TR.35

Retaining ring 12

Name: Retaining ring 12

Model No: 1500TR.35

£0.44

£0.53

Bush 1500TR.36 Spare Part Image

1500TR.36

Bush

Name: Bush

Model No: 1500TR.36

£5.39

£6.47

Pump pedal 1500TR.37 Spare Part Image

1500TR.37

Pump pedal

Name: Pump pedal

Model No: 1500TR.37

£46.61

£55.93

R ring 1500TR.38 Spare Part Image

1500TR.38

R ring

Name: R ring

Model No: 1500TR.38

£0.44

£0.53

Screw 1500TR.39 Spare Part Image

1500TR.39

Screw

Name: Screw

Model No: 1500TR.39

£3.86

£4.63

Pump base ass'y 1500TR.41 Spare Part Image

1500TR.41

Pump base ass'y

Name: Pump base ass'y

Model No: 1500TR.41

£102.59

£123.11

Leg ass'y 1500TR.42 Spare Part Image

1500TR.42

Leg ass'y

Name: Leg ass'y

Model No: 1500TR.42

£61.01

£73.21

Wheel,swivel castor, single bolt (D:88 W:37 B:12 H:170)
 1500TR.45 Spare Part Image

1500TR.45

Wheel,swivel castor, single bolt (D:88 W:37 B:12 H:170)

Name: Wheel,swivel castor, single bolt (D:88 W:37 B:12 H:170)

Model No: 1500TR.45

£19.61

£23.53

O-ring, (Ex: 55.71 In: 50.47 Cs: 2.62) 2200HL.45 Spare Part Image

2200HL.45

O-ring, (Ex: 55.71 In: 50.47 Cs: 2.62)

Name: O-ring, (Ex: 55.71 In: 50.47 Cs: 2.62)

Model No: 2200HL.45

£1.61

£1.93

Spring Pin M4 X 25 800TTJ.227 Spare Part Image

800TTJ.227

Spring Pin M4 X 25

Name: Spring Pin M4 X 25

Model No: 800TTJ.227

£0.44

£0.53

Flat Washer M12 Zinc FWM12.S Spare Part Image

FWM12.S

Flat Washer M12 Zinc

Name: Flat Washer M12 Zinc

Model No: FWM12.S

£0.79

£0.95

Flat Washer M20 FWM20.S Spare Part Image

FWM20.S

Flat Washer M20

Name: Flat Washer M20

Model No: FWM20.S

£0.99

£1.19

Grub screw m5x8 (single) GSM58.S Spare Part Image

GSM58.S

Grub screw m5x8 (single)

Name: Grub screw m5x8 (single)

Model No: GSM58.S

£0.79

£0.95

Hex Head Bolt M12 x 140mm HHB12140.S Spare Part Image

HHB12140.S

Hex Head Bolt M12 x 140mm

Name: Hex Head Bolt M12 x 140mm

Model No: HHB12140.S

£1.49

£1.79

External Circlip 18.5mm ID.

 MC550.24 Spare Part Image

MC550.24

External Circlip 18.5mm ID.

Name: External Circlip 18.5mm ID.

Model No: MC550.24

£0.44

£0.53

O-ring, (Ex: 44.76 In: 37.70 Cs: 3.53) SA316.60 Spare Part Image

SA316.60

O-ring, (Ex: 44.76 In: 37.70 Cs: 3.53)

Name: O-ring, (Ex: 44.76 In: 37.70 Cs: 3.53)

Model No: SA316.60

£1.99

£2.39

Steel Ball 6.0mm SB-6.0 Spare Part Image

SB-6.0

Steel Ball 6.0mm

Name: Steel Ball 6.0mm

Model No: SB-6.0

£0.79

£0.95

Steel ball 9.5mm SB-9.5 Spare Part Image

SB-9.5

Steel ball 9.5mm

Name: Steel ball 9.5mm

Model No: SB-9.5

£0.79

£0.95

Steel Nut M12 Zinc SN12.S Spare Part Image

SN12.S

Steel Nut M12 Zinc

Name: Steel Nut M12 Zinc

Model No: SN12.S

£0.99

£1.19

Steel Nut M12 Domed Zinc SN12.SD Spare Part Image

SN12.SD

Steel Nut M12 Domed Zinc

Name: Steel Nut M12 Domed Zinc

Model No: SN12.SD

£0.49

£0.59

Hex Head Set Screw M12 X 30 Zinc SS1230.S Spare Part Image

SS1230.S

Hex Head Set Screw M12 X 30 Zinc

Name: Hex Head Set Screw M12 X 30 Zinc

Model No: SS1230.S

£0.79

£0.95

Spring Washer M12 Zinc SWM12.S Spare Part Image

SWM12.S

Spring Washer M12 Zinc

Name: Spring Washer M12 Zinc

Model No: SWM12.S

£0.99

£1.19

  • Manufactured to exacting standards, strong construction for durability and suitable for general workshop applications.
  • Spring loaded dead man's safety release control reduces the risk of inadvertent lowering.
  • 2-Way hydraulic unit ensures that the saddle lowers at a controlled speed at all times, even without load.
  • Extra-large castors allow for increased manoeuvrability.
  • Hydraulic unit larger than the economy models for improved performance and durability.
  • Can be fitted with Model No. ADT5 - Adjustable Gearbox Support.

Base Size:

680 x 700mm

Capacity:

1500kg

Fixed/Adjustable Saddle:

Fixed

Maximum Saddle Height:

1950mm

Minimum Saddle Height:

1120mm

Nett Weight:

51kg

Optional Accessories:

ADT5 - Adjustable Gearbox Support

Pump Strokes to Maximum Height:

n/a

Ram Extensions:

1
