Description
• 1 Tonne Model manufactured to exacting standards, strong construction for durability and suitable for general workshop applications.
• Spring loaded dead man's safety release control reduces the risk of inadvertent lowering.
• 2-Way hydraulic unit ensures that the saddle lowers at a controlled speed at all times, even without load.
• Extra-large castors allow for increased manoeuvrability.
• Hydraulic unit larger than the economy models for improved performance and durability.
• Can be fitted with Model No. ADT5 - Adjustable Gearbox Support.
• Spring loaded dead man's safety release control reduces the risk of inadvertent lowering.
• 2-Way hydraulic unit ensures that the saddle lowers at a controlled speed at all times, even without load.
• Extra-large castors allow for increased manoeuvrability.
• Hydraulic unit larger than the economy models for improved performance and durability.
• Can be fitted with Model No. ADT5 - Adjustable Gearbox Support.
Spare Parts
Specification & Documents
Base Size: |
610 x 680mm |
Capacity: |
1000kg |
Fixed/Adjustable Saddle: |
Fixed |
Maximum Saddle Height: |
1950mm |
Minimum Saddle Height: |
1120mm |
Optional Accessories: |
ADT5 - Adjustable Gearbox Support |
Pump Strokes to Maximum Height: |
n/a |
Ram Extensions: |
1 |
Nett Weight: |
47kg |
Barcode: |
5024209805599 |
Declaration of Conformity: |
|
Parts Diagram: |
|
Instructions: |
|
Safety Data Sheet: |
